Introduction:
NC015 Cuni10 is a type of copper-nickel alloy. also known as CuNi10Fe1Mn, is a specific copper-nickel alloy with
approximately 90% copper, 10% nickel, and small amounts of iron and
manganese
This alloy is known for its good corrosion resistance, especially
in marine environments, making it suitable for applications such as
marine hardware, heat exchangers, and condensers.
Application:
Condensers: NC015 Cuni10 is also utilized in the construction of condensers
for power plants, chemical plants, and other industrial facilities
due to its resistance to corrosion and ability to withstand high
temperatures.
Electrical components: The alloy's electrical conductivity makes it suitable for use in
electrical connectors, terminals, and other components where both
electrical and corrosion resistance are required.
Heat exchangers: The alloy's good thermal conductivity and resistance to corrosion
make it ideal for use in heat exchangers for applications such as
HVAC systems, refrigeration units, and chemical processing
equipment.
Advantage:
When compared to other CuNi alloys, such as CuNi30 (70% copper, 30%
nickel) and CuNi90/10 (90% copper, 10% nickel), NC015 Cuni10 has
some distinct characteristics:
Composition: NC015 Cuni10 has a higher copper content compared to
CuNi30 and CuNi90/10, which affects its overall properties such as
corrosion resistance, thermal conductivity, and electrical
conductivity.
Corrosion resistance: NC015 Cuni10 offers good corrosion
resistance, especially in marine environments, due to its higher
copper content. It is often preferred for applications where
exposure to seawater or corrosive environments is a concern.
Overall, the choice between NC015 Cuni10 and other CuNi alloys
depends on the specific requirements of the application, such as
corrosion resistance, mechanical strength, thermal conductivity,
and cost considerations. Each alloy has its own unique properties
that make it suitable for different uses.
Parameter:
Main Chemical composition (%)
| NC015 CuNi10 | Copper | Nickel | Manganese |
| Chemical | balance | 10% | 1~1.5% |
Physical Parameters:
| Type | Resistivity
(μΩ.m20°C) | Max working temperature
(°C) | Tensile strength
(Mpa) | Melting point
(°C) | Density
(g/cm) | TCR
(x10-6/°C)
(20~600°C) | EMF vs Cu
uV/°C
(0~100°C) | Elongation
(%) |
| CuNi10 | 0.15 | 250 | 290 | 1100 | 8.9 | ＜50 | -25 | 15~35% |
Type of product:
| Type | Size(mm) | others |
| Round wire | 0.1~8mm | Customized |
| Flat ribbon wire | W-0.5~5mm | T-0.1~3mm |
| Strip/foil | W-6~250mm | T-0.1~3mm |
| Rod | 8~200mm |
